Film Pendulum Impact Tester ASTM D3420
2000.00 - 20000.00 USD ($)/Set
Product Details:
- Port Size 6 mm PU Tubing
- Specimen Size 100 mm x 100 mm or 100 mm Millimeter (mm)
- Power Supply 220VAC 50Hz / 120VAC 60Hz
- Number of Specimens 1
- Usage pendulum impact testing
- Machine Weight 65kg Kilograms (kg)
- Click to View more
-
Share Your Product:
X
Film Pendulum Impact Tester ASTM D3420 Price And Quantity
- 2000.00 - 20000.00 USD ($)/Set
- 1 Set
Film Pendulum Impact Tester ASTM D3420 Product Specifications
- 6 mm PU Tubing
- pendulum impact testing
- 100 mm x 100 mm or 100 mm Millimeter (mm)
- 65kg Kilograms (kg)
- 220VAC 50Hz / 120VAC 60Hz
- 1
Film Pendulum Impact Tester ASTM D3420 Trade Information
- Jinan
- 10 Set Per Month
- 7 Days
- Veneer Case
- All India
- ISO 9001 CE
Product Description
With the assistance of skilled and dedicated professionals, we bring forth for our clients a wide range of Film Pendulum Impact Tester. Offered tester is basically used for the determination of impact resistant properties of sheets, plastic films, composite films, aluminum foils and other material. Designed to provide absolutely accurate results, this tester is manufactured by our seasoned professionals using optimum quality basic components. Available in several designs and technical specifications as per the requirements of clients, this Film PendulumImpact Tester is offered by us at highly competitive price.
Features:
- Compact design
- High impact strength
- Easy to operate
- Sturdy construction
-
Adjustable range and electronic measurement support various combinations of non-standard test conditions
- Pneumatic specimen clamping, pendulum release mechanism and horizontal adjustment system effectively reduce the errors caused by manual operation
- The system provides automatic statistics of testing data for users convenient viewing
- The instrument is controlled by micro-computer, with LCD, menu interface and PVC operation panel.
- Support LystemTM Lab Data Sharing System for uniform and systematic management of test results and test reports
Test Principle
The impact resistance of films could be obtained by measuring the energy consumed by hemispheric impact head to make films ruptured, under the certain impacting conditions.
This instrument conforms to various national and international standards:
GB 8809-88, ASTM D3420,NF T54-116
Applications
This instrument is applicable to the determination of impact resistance of:
| Items | Specifications |
|---|---|
| Impact Energy | 1 J, 2 J, 3 J (Standard) |
| Resolution | 0.001 J |
| Specimen Size | 100 mm x 100 mm or 100 mm |
| Energy Analysis Accuracy | + 0.5% |
| Net Weight | 65 kg |
Technical Specifications
| Items | Specifications |
|---|---|
| Impact Energy | 1J, 2J, 3J (Standard) |
| Resolution | 0.001J |
| Impact Head Size | 25.4mm, 19mm, 12.7mm (Customization is available) |
| Specimen Clamp Diameter | 89mm, 60mm |
| Specimen Size | 100 mm x 100 mm or 100mm |
| Gas Supply Pressure | 0.6 MPa (Not in supply scope) |
| Port Size | 6mm PU Tubing |
| Instrument Size | 600 mm (L) x 390 mm (W) x 600 mm (H) |
| Power Supply | AC 220V 50Hz |
| Net Weight | 64 kg |
Configurations
| Standard Configurations | Main body, Pendulum of 1J, 2J and 3J, Standard Impact Head of 25.4mm and 19mm, Standard Clamp Plate of 89mm and 60mm (including O-ring), and Micro Printer |
| Optional Parts | Professional Software, Communication Cable, Customized Impact Head, and O-ring |
| Note |
|
